Precision Flush Cut Diagonal Cutter with Tapered & Relieved Head & ESD Safe Handle for hard materials

ESD-SAFE
$92.00
Mfr Part NoRX8147PS
SKU59-RX8147PS
Authorized Lindström Distributor Genuine factory-new stock
In Stock
Request a Quote
Shipping calculated at checkout
Expert Support
Securely Packaged
Tracking Provided
30-Day Returns

Overview

  • Products designed to get precise cuts on guidewires, catheter coil wires and cardiology and urology stents
  • Hard wire cutters can be used on single or multiple filars and for lateral or internal coil cuts
  • Sharp, fully aligned cutting edges
  • Material: High performance alloy steel
  • Precision induction hardened edges 63-65 HRC
  • Screw joint minimizes friction and maximizes alignment of cutting edges
  • ESD safe handles in synthetic material with return spring
  • Numerically controlled machining guarantees edge angle accuracy and contact, increasing the tools reliability and consistency

Specifications

Cutting
Head typeTapered & Relieved
Cut resultFlush
Cutting capacity0.1–0.8 mm / 0.004–0.03 in
Material, ESD & Origin
HandleErgo
Country of originSpain
Dimensions & Weight
Length135.5 mm / 5.33 in
Head height10.5 mm / 0.41 in
Head width10 mm / 0.39 in
Head thickness6 mm / 0.24 in
Head sizeS
Weight68 g

In this series

Each model in this series is its own page.

Model Cut result Head size Cutting capacity ESD View →
59-RX8147PS (current) Flush S 0.1–0.8 mm / 0.004–0.03 in ✓
59-BAH8147 Flush S 0.1–1.0 mm / 0.01–0.04 in ✓ View →
59-RX8137 Flush XS 0.1–0.8 mm / 0.004–0.03 in ✓ View →
59-8167L_ Flush L 0.3–1.5 mm / 0.01–0.06 in ✓ View →
59-BAH8157 Flush M 0.2–1.25 mm / 0.01–0.05 in ✓ View →
59-8147 Flush S 0.1–1.0 mm / 0.01–0.04 in ✓ View →

Documents & Downloads

Datasheet ESD-Safe Certificate Installation & Care Warranty Statement
